FOUR HDMI INPUT FOXTEL® APPROVED MODULATOR WITH RCA AUDIO OUT - ZYCAST

4X HDMI TO DIGITAL RF HD DVB-T MODULATOR WITH AUDIO OUT

KT-FX4DA allows one of the modulators sources audio (output via RCA) to distribute to a PA amplifier with adjustable lip-sync if required, ideal solution for pub and club installations.
The KT-FX4DA is a genuine Foxtel® approved quad input (HDMI) 1080p Full-HD digital modulator that encodes HDMI signals to any Australian DTV channel for easy, convenient HD-TV AV distribution. Pre-programmed with Foxtel® approved channel listing. With an output level of 90dB and MER of >38dB, the KT-FX4DA makes use of video compression via H.264 AVC (MPEG-4) and audio compression via MPEG Layer II/AAC to distribute four crystal-clear full HD pictures over a new or existing TV coaxial cable installation. In addition, the KT-FX4DA allows one of the modulators sources audio (output via RCA) to distribute to a PA amplifier plus you can also easily adjust the delay in the audio signal for perfect lip-sync if required. This makes the KT-FX4DA an ideal solution for pub and club installations. Programming of the KT-FX4DA is done via a web GUI and front LCD panel. Frequency range of 177.5MHz to 816.5MHz (CH6 to CH69).

Foxtel Approved Number: F31062

INPUT
Number of Inputs: 4
Video Input: HDMI
Video Input Level: 0.7 - 1.4V (Peak to Peak)
Video Mode: PAL
Audio Mode: Stereo

OUTPUT
Frequency Range: 177.5 MHz to 816.5 MHz (6 to 69)
HDMI Loop through: No
Output Level: 85dB
MER: >38dB
DELAYED AUDIO
Delayed Audio Output: Yes
Delay: 0 to 20 Seconds
Connection Type: RCA / Stereo

MODULATION
Video Resolution: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compression: H.264 AVC (MPEG-4)
Audio Compression: MPEG Layer II / AAC
Video bitrateSD: 1 Mbps to 9 Mbps (Default 5 Mbps)
Video bitrateHD: 12 Mbps to 24 Mbps (Default 24 Mbps)
LCN: AU (APN)
Carrier: 2K / 8K
GI: 1/32
FEC: 7/8
Constellations: 16 QAM / 64 QAM
MANAGEMENT / PROGRAMMING
Front LCD: Yes
Web GUI: Yes

GENERAL
Power Supply Type: External
Power Supply: 2x 12V DC 4A
Redundant PSU: Yes
Operating Temperature: 0c to +45c
Storage Temperature: -0c to +60c
Dimensions: 482mm x 208mm x 44mm
Weight: 2.76 Kg
Warranty: 3 Years
