HDMI SPLITTERS 4K60 - CYPRESS
18GBPS BANDWIDTH

The 1 by 2, 4, 8, 10 HDMI splitters with HDCP2.2 are advanced solutions for splitting a single HDMI input into multiple outputs. They support video bandwidth at up to 18Gbps and provide high-performance audio and video output up to 4K2K @ 60Hz (YUV444) resolution. These units also support HDR (High Dynamic Range Imaging) function, which can produce more luminous radiance contrasting and colourful pictures for a better experience. They support high resolution digital audio formats such as LPCM 7.1CH, Dolby Digital Plus, Dolby Atmos and DTS-HD master audio, audio sampling rate up to 192kHz. There are input and output indications on the panel, which will turn on when detected, system reset function allows these units to set the TV to its default HDMI input.

HDMI (with 6G audio/video support), HDCP 2.2 and DVI compliant (note: does not support 'Deep Colour'/colour space - YCbCr 422/444)
Supports System Reset function (CEC active source command)
Simultaneous display of a single Ultra High-Definition source to multiple UHDTV displays
3D passthrough with compatible 3D source and 3D TV
Supports UHDTV resolutions up to 4K2K: 3840×2160@24/25/30/50/60Hz & 4096×2160@24/25/30/60Hz
Supports pass-through of high definition audio: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH, Dolby TrueHD, DTS-HD Master Audio & Dolby Atmos
HDCP 2.2 and HDCP1.4 compliant
HDMI input supports 'Standard' mode and 'TV' mode EDID settings.
